NodeMCU ESP8266 development board with 4 MB internal flash and additional 32 Mbit (4 MB) external flash memory, equipped with the CH340G USB interface for broad compatibility with Windows, macOS, and Linux. Supplied with Lua firmware, programmable via Arduino IDE or Lua scripting, and designed for IoT and WiFi-enabled projects.
Microcontroller: ESP8266EX
Internal flash: 4 MB
External flash: 32 Mbit (4 MB)
USB interface: CH340G
Supply voltage: 4 to 9 V via VIN pin or 5 V via USB
Clock speed: 80 MHz
GPIO: 10 pins with PWM, I2C, SPI, 1-Wire support
ADC: 1 channel
Communication: WiFi 802.11 b/g/n, supports access point, station, and webserver modes
Programming: Arduino IDE or Lua scripting
API: event-driven for network applications
The combination of integrated WiFi, extended memory, and multiple communication interfaces makes this board suitable for IoT development, wireless sensor networks, home automation, and general-purpose WiFi-connected projects.
Bought three of these a little while ago and finally got them running. Have not figured out the Lua thing yet so just using them as generic ESP8266 boards. Using Arduino IDE and downloaded board manager for the ESP8266 chip I have been able run many of the demo programs, including the wifi demos. Successfully made a little http server that lets you toggle one of the LED from a webpage served by the ESP8266. Have not found the perfect “Board” to use under the Arduino IDE but NodeMCU 1.0 seems to work. Now cross checking I/O and LED definitions looking for the best match to the boards hardware features. LED’s are I/O 2 and 16, onboard switch is I/O 0
